UWB Asset Tracker
The UWB Asset Tracker combines BLE and UWB for reliable real-time asset tracking, helping teams locate assets faster, improve utilization, and reduce loss across logistics, healthcare, and industrial environments.
Overview
Find Assets Faster. Manage Them Smarter
Supports screw, cable tie, 3M adhesive, and magnetic mounting for flexible installation across different assets. Up to IP67 protection and IK08 impact resistance ensure reliable operation in demanding environments.
Wide-Coverage, High-Precision Positioning
Supports BLE and UWB to balance coverage and accuracy across different scenarios. BLE enables wide-area tracking, while UWB delivers positioning accuracy down to 10 cm with up to 50 m range.
Multi-Standard, Open Compatibility
Available in FiRa- and omlox-compatible versions, the Asset Tracker integrates flexibly with different RTLS ecosystems, reducing integration complexity and supporting easier system expansion as deployment needs evolve.
Flexible Power Options, Lower Maintenance
Available in battery-powered and wired versions for different asset types. Wired models support continuous power from equipment such as forklifts, while battery models deliver up to 5 years of operation, helping reduce maintenance effort.
Mount Anywhere, Rugged Protection
Supports screw, cable tie, 3M adhesive, and magnetic mounting for flexible installation across different assets. Up to IP67 protection and IK08 impact resistance ensure reliable operation in demanding environments.
Specifications
| Product Name | UWB Asset Tracker | UWB Vehicle Tracker |
|---|---|---|
| Product Model | AT21 | AT22 |
| UWB Positioning | ||
| Frequency | Channel 5: CF 6489.6 MHz | Channel 5: CF 6489.6 MHz |
| Frequency | Channel 9: CF 7987.2 MHz | Channel 9: CF 7987.2 MHz |
| Bandwidth | 500 MHz | 500 MHz |
| Communication Range | Up to 50 m (LOS) | Up to 50 m (LOS) |
| BLE Configuration and Positioning | ||
| Version | BLE 5.4 | BLE 5.4 |
| Frequency | 2400~2480 MHz | 2400~2480 MHz |
| Communication Range | 50m | 50m |
| Power Supply | ||
| Power Supply | 2 × 1200 mAh ER14250 Li-SOCl2 Replaceable Batteries | DC 5-24V |
| Battery Life | 5 Years, factory default configuration | NA |
| Battery Life | May vary by use case and configuration | NA |
| Operating Conditions | ||
| Operating/Storage Humidity | 10% - 90% RH, non-condensing | 10% - 90% RH, non-condensing |
| Storage/Operating Temperature | -20-60℃ (-22°F - 176°F) | -20-60℃ (-22°F - 176°F) |
| Protection Rating | IP67, IK08 | IP65, IK08 |
| Physical Characteristics | ||
| Button | Button *1 for power on/off, reset, and pairing | Button *1 for reset and pairing |
| Demension | 71.8mm x 48.1mm x 28.7mm | 71.8mm x 48.1mm x 25.2mm |
| Weight | 71g, with 2 x batteries (adhesive tape attached) | 68g |
| Mounting options | Double-sided Tape Mounting | Double-sided Tape Mounting |
| Mounting options | Wall Screw Mounting | Wall Screw Mounting |
| Mounting options | Cable Tie Mounting | Cable Tie Mounting |
| Mounting options | Magnetic Mounting | |
