Wireless Occupancy Sensor
Occupancy Sensor features passive infrared (PIR) technology for movements detection and automatically switches lighting on and off upon occupancy/vacancy detected. Effectively manage energy consumption with integral ambient light harvesting and dimming.
• Compact design
• 10-year battery lifetime
• Ambient light recognition
• Major/Minor motion coverage
• Versatile commercial applications
• 10-year battery lifetime
• Ambient light recognition
• Major/Minor motion coverage
• Versatile commercial applications
Specifications
Name
Value
Input Voltage
3V DC
Integrated Sensor
Motion sensor & Light sensor
Communication Protocol
Zigbee
Dimensions(mm)
Φ90*32
IP Grade
IP20
Name
Value
Operating Temperature
-10~50°C, non-condensing environment
Mounting Way
Ceiling mounted
Light Sensor Accuracy
Up to 900 lux, accurate to ±15 lux
Detection Range
@2.5m H: major Φ6.5m; minor Φ3.5m
@3m H: major Φ7.5m; minor Φ4.5m
@4m H: major Φ8.5m; minor Φ4m
@3m H: major Φ7.5m; minor Φ4.5m
@4m H: major Φ8.5m; minor Φ4m
