Door Window Sensor
The Leedarson door window sensor is designed for scenes in home automation and security systems, the door window sensor lets you know when door or window is opened and can trigger different actions in response to open action (or close action). To use the door window sensor to monitor your home anywhere, any time.
• With hall effect sensor which is more stable and high reliability than traditional reed switch sensor.
• Easy installation with screws or foam tape (both included).
• Low battery alarm.
• Equipped with an anti-tamper switch that reports any dismantling.
• Slim design blends in with door or window frame.
• Award iF DESIGN 2019.
• Easy installation with screws or foam tape (both included).
• Low battery alarm.
• Equipped with an anti-tamper switch that reports any dismantling.
• Slim design blends in with door or window frame.
• Award iF DESIGN 2019.
Specifications
Name
Value
Model Number
8A-SS-ZE-H0
Protocol
Zigbee 3.0
Detection Technology
Hall effect
Magnetic Gap
20mm
Power Source
3VDC, CR2032 x 1
Battery Life
2 Years
Name
Value
Radio Frequency
Zigbee 2.4G Hz
Operating Range
130ft. (40m) LOS
Operating Temperature
32°F ~ 104°F(0°C ~ 40°C)
Operating Humidity
Up to 85%, Non-condensing
Mounting
Screw or Foam Tape
Certification
FCC,CE
